Physical Design Implementation
From RTL to GDSII, we provide comprehensive physical design services ensuring optimal performance, power, and area for your silicon designs.
Clock Gating

Floor planning

Strategic chip floorplanning for optimal area, power, and timing

  • Hierarchical floorplanning
  • Power grid planning
  • I/O placement optimization
  • Macro placement strategies
physicaldesign Gating

Place & Route

Advanced placement and routing for high-performance designs

  • Global and detailed placement
  • Clock tree synthesis (CTS)
  • Multi-layer routing optimization
  • via minimization techniques
Multi-Voltage Domains

Static Timing Analysis

Comprehensive timing analysis and closure

  • Setup and hold timing analysis
  • Multi-corner multi-mode (MCMM)
  • Clock domain crossing (CDC) analysis
  • Timing ECO implementation
physicaldesign Intent Specification

Signoff & Verification

Automate low-physicaldesign design using industry-standard formats

  • DRC/LVS verification
  • Parasitic extraction
  • Power integrity analysis
  • GDSII generation and validation
Design for Test (DFT) Services
Seamless integration of custom intellectual property blocks with ARM/ARC/RISC-V based cores.
GPS Engines

Scan Insertion

Comprehensive scan chain implementation for manufacturing test

  • Dynamic Voltage and Frequency Scaling (DVFS)
  • Adaptive Body Biasing (ABB)
  • Near-Threshold Computing
  • Power-Aware Synthesis
ATPG & Test Patterns

ATPG & Test Patterns

Automatic test pattern generation for maximum fault coverage

  • Stuck-at fault ATPG
  • Transition delay fault ATPG
  • Path delay fault testing
  • Low-power test patterns
Memory BIST

Memory BIST

Built-in self-test for embedded memories

  • MBIST controller design
  • Memory repair mechanisms
  • Diagnostic and debug features
  • Multi-port memory testing
Industrial

Boundary Scan

IEEE 1149.1 boundary scan implementation

  • JTAG controller integration
  • Boundary scan cell insertion
  • Board-level test support
  • In-system programming
physicaldesign icon

Advanced Technology
Support

We support the latest process technologies and design methodologies, ensuring your designs are optimized for cutting-edge manufacturing processes.

  • Advanced Process Nodes (7nm, 5nm, 3nm)
  • FinFET Technology
  • Multi-Patterning Techniques
  • 3D IC Design
  • Package-Chip Co-design
  • Chiplet Integration

Implementation Flow

Floorplanning & Power Planning

Optimal chip architecture and power grid design

01

Placement & CTS

Cell placement and clock tree synthesis

02

Routing & Optimization

Global and detailed routing with timing closure

03

DFT & Signoff

Test insertion and final verification

04
Ready to Accelerate Your Silicon Development?

Partner with TOSIL Systems for world-class silicon engineering services. Let's discuss how we can bring your silicon vision to reality.
